Delta Orca

Intel® Xeon® 6 Processor-Based Server for Storage Infrastructure

Description

The platform is built on Intel® Xeon® 6 processors and is a high-performance device designed for data storage infrastructure. Thanks to its high density and support for the latest PCIe Gen5 NVMe SSDs, the server is ideal for building high-performance data storage systems.

Specifications

Up to 80 high-performance Granite Rapids P-cores or 96 energy-efficient Sierra Forest E-cores
Up to 2 TB of DDR5 RAM up to 6400 MT/s
Up to 20 7mm U.2 PCIe Gen5 NVMe SSD or up to 10 15mm U.2 PCIe Gen5 NVMe SSD
2x M.2 PCIe Gen5 NVMe for OS
Delta Hybrid Cooling system for maximum processor operation time in Max Turbo Boost mode
Support for network adapters with throughput up to 400 Gbps
Extensive monitoring and management functionality in the system Delta BMC

Up to 96 energy efficient

Sierra Forest E-cores

Up to 20 drives

U.2 PCIe Gen5 NVMe SSD

Interface

Applications

Lakehouse architecture

High-performance Intel® Xeon® 6 processor cores and modern NVMe Gen5 drives enable efficient use of Lakehouse infrastructure where a combination of different storage layers is required

Object storage

The Delta Orca server can be used as an object storage solution for a wide variety of scenarios, such as data lakes, unstructured data storage, and more

Cloud infrastructures

Delta Orca can be used to support web servers, databases, and microservices thanks to the large number of high-performance cores of Intel® Xeon® 6 processors

Advantages

Latest technologies

Featuring a cutting-edge architecture, the Intel® Xeon® 6 Delta Orca line delivers an impressive core count, expanding data center capabilities to meet the demands of more demanding workloads

High density

Delta Orca has the ability to install up to 20 drives, and thanks to the OCP architecture, two servers fit in two OUs, which saves space in the data center
